PART NUMBER: SCC1005
Introducing the CINDER™ 40. This 40-amp charge controller can regulate up to 800 watts at 12 volts or 1,600 watts at 24 volts and is compatible with LiFePO4/Li-Ion, Lithium-Titanate (LTO), AGM, Conventional lead-acid (wet), and calcium batteries. Provide your batteries and solar panels with built-in protection. Auto-detect 12-volt and 24-volt battery configurations without touching the unit.
The newly designed CINDER™ line of charge controllers will come standard with the ability to communicate utilizing the RV-C data protocol. The RV-C standard is the latest way for your RV appliances to shares information regarding energy generation or consumption. This will allow all of the smart devices on the network to shift resources efficiently.
Protects and Regulates
All our charge controllers use pulse width modulation (PWM) and five stages of charging to regulate the flow the electricity to your battery. This protects your battery from overcharging, expands your battery’s lifespan, and keeps your panel safe from backflow electrical currents, among many other protections and benefits.
Real-Time Monitor
Bright LED indicators allow visual monitoring of your battery conditions on the face of the controller. Use the free Apple or Android app to monitor charging current, charging capacity (amps per hour), select your battery type, and system faults.
Flexible and Customizable
Our Cinder 40-amp charge controller is weather resistant and can be surface-mounted on your wall.
CINDER™ 40-Amp Charge Controller Specs:
-
12 Volt Max Solar Input of 800W
-
24 Volt Max Solar Input of 1,600W
-
Input Amps: 40
-
RV-C Enabled: Yes
-
Lithium Charging Profile: Yes
-
Bluetooth: Built-In
-
Smartphone Apps: FREE (Currently unavailable) and downloadable app
-
Pulsetech Technology: Patented Desulfation Will Prolong Lead-Acid Battery Life By 3X
-
Mounting Option: Surface Mount
- Dimensions: 8" x 5.3" x 2"
